- 【HIGH QUALITY & DURABLE】- The high-quality plastic and aluminum alloy is extremely strong, ensuring a long service life. With a fuel consumption of just 0.26gal/h, the 0.31gal tank can continuously work for more than one hour.
- 【EXCELLENT EFFICIENCY】- The 4-stroke 6hp engine, with a thrust force of up to 1653lbs, will provide strong power for stable driving. A heavy-duty three-blade plastic propeller reduces drag and balances thrust for optimum performance.
- 【HIGH PERFORMANCE】- Vertical mount engine design and superior carbonation system with primer bulb can increase power, efficiency, performance, and durability. Start-in-gear protection/clutch feature prohibits prop rotation while idling to prevent danger and machine damage. Multiple heat vents on the housing provide good ventilation and prevent the engine from overheating to improve its stability and reliability.
- 【INFINITELY VARIABLE SPEED & FLEXIBLE STEERING】- You can enjoy a free and fast speed by turning the throttle handle for infinitely variable speed from 10-12km/h. The flexible 360° steering function allows you to easily control the direction of the boat so that reversing can be done by rotating 180 degrees. Manual lift/tilt feature is convenient for shallow water operation.
- 【WIDE RANGE OF APPLICATIONS】- This product is suitable for small boats, such as inflatable boats, iron boats, plastic boats, fiberglass boats, and wooden boats. It is applicable to water operations in rivers, lakes, reservoirs, fish ponds, etc.
Specifications
- Material: Plastic and Aluminium Alloy
- Color: Black
- Model: Single Cylinder
- Max. Output: 6.0HP
- Stroke: 4-stroke
- Displacement: 140CC
- Fuel Consumption: 1L/H (0.23gal/H)
- Bore and Stroke: 61x48mm/2.4x1.88in
- Gear Ratio: 1:1.5(16/24)
- Max. Power: 3.75kw
- Max. Speed: 4500-5500RPM
- Speed: 10-12 km/h (6.21-7.45 mph) ( Depending on the Environment, Water, Hull Load speed will be Different)
- Ignition System:TCI
- Startup Model: Hand Pull
- Control System: Tiller Control
- Cooling System: Air-cooling
- Trim and Tilt System: Manual Tilt
- Recommended Engine Oil: Outboard 4-stroke Engine Oil
- Thrust:750kg/1653lbs
- Recommended Propeller Range(in): 3-7 1/2"x5"
- Gross Weight: 24.7kg/54.45lb
- Net Weight: 19.7kg/43.43lb
- Clamping Range: 0-4cm/0-1.57in
- Product Size: 40*38*108cm/15.75*14.96*42.52in
- Built-in Fuel Tank Volume: 1.2L/0.31gal
- Thrust Force: 750kg/1653lbs
Package Included
1* Outboard Engine
1* Funnel
1* English User Manual
All Accessories for Installation
Notes
1. Add gasoline and engine oil to the box accordingly. (a box to add gasoline and a box to add engine oil) Don't mix the gasoline with engine oil.
2. Please note that the motor couldn't reach the reverse gear.
3. Please read the manual completely before installation and use, and pay particular attention to the safety instructions included.
4. Please note that the exact speed of travel depends on the shape of your boat, weight, water, wind and other factors.
